1/44 PAGE
PARTS LIST
A-5VL
NOTE:
! : Safety mark
<MDC>: Canadian model
NOTE:
<MMB>: Britain model
THE COMPONENTS IDENTIFIED BY MARK ! ARE
<MDF>: Taiwan model CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
<MMR>: China model REPLACE ONLY WITH PART NUMBER SPECIFIED.
<B>: Black color
<S>: Silver color
NSP: Not service part
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO.
REMARKS
EXPV
A001 CHASSIS -- 1 27100534B
N NSP
EXPV
A002 HEAT SINK (L) 2 27160639A
N
EXPV
A003 HEAT SINK (R) 1 27160640A
N
EXPV
A005 SPACER (HO) 4 27270525
N
EXPV
A006 SPACER T0.5*8*3.5 4 27270463 CHASSIS
EXPV
A007 HOLDER KGLS-6S 14 27190011 CHASSIS
EXPV
A008 WIRE TIE BSK-1 3 260208
EXPV
A009 SCREW 3TTW+8B(3BC) 6 831430088GR HEAT SINK
EXPV
A011 SCREW 3P+6FN(3BC) 6 82143006GR TR-HEAT SINK
EXPV
A012 SCREW 3P+10FN(3BC) 3 82143010GR AMP/DG PWB-HEAT SINK
EXPV
A013 SCREW 4TTC+8C(3BC) 8 830440089GR TRANS
EXPV
A014 CLAMP HL-18-0 2 27301394
EXPV
A015 CLAMP WS-2NS 1 27300833
EXPV
A017 ISO SHEET M80 D-2 4 223037
EXPV
A018 TR ACCY AC316A 4 223033
EXPV
A019 SHEET (H) 2 29096096
N
CHASSIS-HEAT SINK
EXPV
A020 KNOB (PHONO) 1 28326738
N
EXPV
A021 BUSHING TB-0813 1 28170094
N
REAR PANEL
EXPV
A022 CLAMP HL-28-0 1 27301396 MAIN PWB
EXPV
A023 SPACER T1*8*3.2PTFE 2 27270527
N
HT(DIG PWB)
