A-5VL
SERVICE PROCEDURE
1. Replacing the fuses
REF.NO.
F901
F901
PART NO.
DESCRIPTION
3.15A-UL/T-233
This symbol located near the fuse indicates that the
fuse used is show operating type, For continued protection against
fire hazard, replace with same type fuse , For fuse rating, refer to
the marking adjust to the symbol.
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre.
PART NAME
FUSE
FUSE
Q'TY
1
1
REMARKS
<DC>
<PA>
2. Setting position before shipment.
<Notes>
<DC> : Canadian model
<MB> : Britain model
<MR> : China model
252323GR
252073GR1.6A-SE-EAK
(1) Power SW OFF
(2) Selector CD
(3) Speaker A
(4) Bass Center
(5) Treble Center
(6) Balance Center
(7) Volume Min.
(8) MM/MC MM position
(9) Tone/Direct Direct
3. Initialize setting
Turn on the unit.
Press “DIRECT” mode button.
