TX-SR343/444/HT-R494
Service Information Mode
Displaying Service information
This service information display system is helpful in analyze the status when the unit goes into
Protect mode and is powered off. Pay attention that the status will change if a button is pushed.
How to enter to service information mode.
Step1 : Set the volume level as 25.
Step2 : [TONE+] + [ON/STANDBY] x 2
Step3 : [SETUP]
Step4 : [SETUP]
To exit the service information mode.
[ON/STANDBY]
(REF.: To initialize the data in the service information.)
[RETURN]
Listening Mode Code List
Service Information Mode
01
C_LM_LAST
02
C_LM_PURE
03
C_LM_DIRECT
04
C_LM_STEREO
05
C_LM_MONO
20
C_LM_SURR
50
C_LM_THX_MUSIC
70
C_LM_THX_GAME
90
C_LM_THX_CINEMA
A0
C_LM_THX_U2GAME
A8
C_LM_THX_U2MUSIC
B0
C_LM_THX_U2CINEMA
D0
C_LM_AUDYSSEY
48
C_LM_DTSSS
06
C_LM_ORCHESTRA
07
C_LM_UNPLUGGED
08
C_LM_STUDIOMIX
09
C_LM_TVLOGIC
0A
C_LM_ALLCHST
0B
C_LM_FULLMONO
0C
C_LM_TD
F1
C_LM_TESTTONE
F2
C_LM_TESTTHR
F3
C_LM_TESTAUTO
F4
C_LM_ASC
F5
C_LM_FLASH
F6
C_LM_DEBUGMODE
F7
C_LM_FLASH2
F8
C_LM_FLASH3
F9
C_LM_FLASH4
FA
C_LM_FLASH_CHECK
0D
C_LM_RPG
0E
C_LM_ACTION
0F
C_LM_ROCKBAND
10
C_LM_SPORTS
Protect Data CLR
Normal display
M1.xx / xxxxxALA
The version of main microprocessor.
(displayed only for 3 seconds)
- 8 0 F 2 7 D D
Power off Cause
T : Thermal Protect
V : Voltage Protect
I : Current Protect
- : Other
Temperature
: xx F or xx C
Volume Level
Listening Mode
Please see the “Listening Mode
code list” on the right.
01: 23 10h
Information Displayed
(Record this Information)
Time after Power on
xx : xx
Time after Power on
xx : xx
