HT-R494_C(B)MDC
<Note>
Parts marked by "NSP" are generally unavailable because <Notes>
they are not in our Master Spare Parts List. (B) : Black color model
<MDC> : 120V
Canadian/USA/(Mexico) model
: NSP
HT-R494_C(B)MDC
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TRANSISTOR 2SC5198-O 1 2203063
Q6050 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6050 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6050 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6051 TRANSISTOR 2SC5198-O 1 2203063
Q6051 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6051 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6051 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6052 TRANSISTOR 2SC5198-O 1 2203063
Q6052 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6052 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6052 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6053 TRANSISTOR 2SC5198-O 1 2203063
Q6053 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6053 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6053 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6054 TRANSISTOR 2SC5198-O 1 2203063
Q6054 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6054 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6054 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6055 TRANSISTOR 2SC5198-O 1 2203063
Q6055 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6055 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6055 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6056 TRANSISTOR 2SC5198-O 1 2203063
Q6056 or TRANSISTOR 2SC4468-O ( 1) 2202523
Q6056 or TRANSISTOR 2SC4468-P ( 1) 2202526
Q6056 or TRANSISTOR 2SC5198-R ( 1) 2203062
Q6060 TRANSISTOR 2SA1941-O 1 2203053
Q6060 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6060 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6060 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6061 TRANSISTOR 2SA1941-O 1 2203053
Q6061 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6061 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6061 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6062 TRANSISTOR 2SA1941-O 1 2203053
Q6062 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6062 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6062 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6063 TRANSISTOR 2SA1941-O 1 2203053
Q6063 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6063 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6063 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6064 TRANSISTOR 2SA1941-O 1 2203053
Q6064 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6064 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6064 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6065 TRANSISTOR 2SA1941-O 1 2203053
Q6065 or TRANSISTOR 2SA1695-O ( 1) 2202513
Q6065 or TRANSISTOR 2SA1695-P ( 1) 2202516
Q6065 or TRANSISTOR 2SA1941-R ( 1) 2203052
Q6066 TRANSISTOR 2SA1941-O 1 2203053
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
