Onkyo HT-R494 User Manual

4/39 PAGE
HT-R494_C(B)MDC
PC BOARD PARTS LIST
U001 BAAF-1712-1G : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D4173 ZENER DIODE DZ2J068M0L 1 224760680R2
1
D4173 or ZENER DIODE UDZS6.8B ( 1) 224550680R2
1
D4174 ZENER DIODE DZ2J068M0L 1 224760680R2
1
D4174 or ZENER DIODE UDZS6.8B ( 1) 224550680R2
1
D4209 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4209 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D4219 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4219 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D4300 DIODE RL1N4003 1 22380260T
1
D4301 DIODE RL1N4003 1 22380260T
1
D4302 DIODE RL1N4003 1 22380260T
1
D4303 DIODE RL1N4003 1 22380260T
1
D4304 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4304 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D4305 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D4305 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D5003 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5003 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5004 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5004 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5005 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5005 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5006 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5006 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D6000 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6000 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6001 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6001 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6002 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6002 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6003 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6003 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6004 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6004 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6005 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6005 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6006 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6006 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6010 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6010 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6011 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6011 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6012 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6012 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6013 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6013 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6014 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6014 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6015 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6015 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6016 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6016 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6020 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6020 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6021 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6021 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6022 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6022 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D6023 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D6023 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
