Onkyo HT-S570 User Manual

8
SN 29343900
(C) Copyright 2004 ONKYO CORPORATION Japan. All rights reserved.
D0407-1
http://www.onkyo.com/
HOMEPAGE
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8124
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.onkyo.net
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039
Specifications
■ Powered Subwoofer (SKW-320X)
Type: Powered Bass-reflex
Input sensitivity/impedance: 220 mV /15 k
Ω
Maximum output power: 100 W (Dynamic Power)
Frequency response: 35 Hz–150 Hz
Cabinet capacity: 0.91 cubic feet (26 Litter)
Dimensions (W
× H × D): 9-1/16 × 17-13/16 × 15-7/8
inch
(230
× 436 × 404 mm)
Weight: 24.7 lbs (11.2 kg)
Speaker: 8 inch Cone
Power supply: AC 120 V, 60 Hz
Power consumption: 75 W
Other: Auto-standby function
■ Front Speaker (SKF-320F)
Type: 2 Way Bass-reflex
Impedance: 8
Ω
Maximum input power: 100 W
Output sound pressure level: 76 dB/W/m
Frequency response: 70 Hz–50 kHz
Crossover frequency: 4.5 kHz
Cabinet capacity: 0.035 cubic feet (1.0 Litter)
Dimensions (W
× H × D): 4 × 6-5/8 × 4-15/16 inch
(101
× 169 × 126 mm)
Weight: 2.6 lbs (1.2 kg)
Speaker:
Woofer: 3-1/8 inch Cone
Tweeter: 1 inch Balanced Dome
Terminal: Spring type Color coded
Other: Magnetic shielding
■ Center Speaker (SKC-320C)
Type: 2 Way Bass-reflex
Impedance: 8
Ω
Maximum input power: 100 W
Output sound pressure level: 78 dB/W/m
Frequency response: 70 Hz–50 kHz
Crossover frequency: 4.5 kHz
Cabinet capacity: 0.057 cubic feet (1.6 Litter)
Dimensions (W
× H × D): 10-3/8 × 4 × 4-15/16 inch
(264
× 101 × 126 mm)
Weight: 4.4 lbs (2.0 kg)
Speaker:
Woofer: 3-1/8 inch Cone x 2
Tweeter: 1 inch Balanced Dome
Terminal: Spring type Color coded
Other: Magnetic shielding
■ Surround Speaker (SKM-320S)
Type: 2 Way Bass-Reflex
Impedance: 8
Ω
Maximum input power: 100 W
Output sound pressure level: 79 dB/W/m
Frequency response: 70 Hz–30 kHz
Crossover frequency: 10 kHz
Cabinet capacity: 0.035 cubic feet (1.0 Litter)
Dimensions (W
× H × D): 4 × 6-5/8 × 4-15/16 inch
(101
× 169 × 126mm)
Weight: 1.8 lbs. (0.8 kg)
Speaker:
Woofer: 3-1/8 inch Cone Woofer
Tweeter: 3/4 inch Celamic Tweeter
Terminal: Spring type Color coded
Specifications and appearance are subject to change
without prior notice.
