Onkyo NS-6130 User Manual

17
> Before Start > Part Names > Install > Initial Setup >Playback
Supplementary information | Advanced Setup | Others
E
N
Music Server
It is possible to stream music files stored on PCs or NAS
devices connected to the same network as this unit. The
network servers this unit is compatible with are those PCs
with players installed that have the server functionality of
Windows Media
®
Player 11 or 12, or NAS that are
compatible with home network functionality. You may need
to make some settings in advance to use Windows Media
®
Player 11 or 12. Note that only music files registered in the
library of Windows Media
®
Player can be played.
Configuring Windows Media
®
Player
∫ Windows Media
®
Player 11
1. Turn on your PC and start Windows Media
®
Player 11.
2. In the "Library" menu, select "Media Sharing" to display a
dialog box.
3. Select the "Share my media" check box, and then click
"OK" to display the compatible devices.
4. Select this unit, and then click "Allow".
0 When it is clicked, the corresponding icon is checked.
5. Click "OK" to close the dialog.
0 Depending of the version of Windows Media
®
Player,
there may be differences in the names of items you can
select.
∫ Windows Media
®
Player 12
1. Turn on your PC and start Windows Media
®
Player 12.
2. In the "Stream" menu, select "Turn on media streaming"
to display a dialog box.
0 If media streaming is already turned on, select "More
streaming options..." in the "Stream" menu to list players
in the network, and then go to step 4.
3. Click "Turn on media streaming" to list players in the
network.
4. Select this unit in "Media streaming options" and check
that it is set to "Allow".
5. Click "OK" to close the dialog.
0 Depending of the version of Windows Media
®
Player,
there may be differences in the names of items you can
select.
Playing
1. Turn the unit on.
2. Start the server (Windows Media
®
Player 11, Windows
Media
®
Player 12, or NAS device) containing the music
files to play.
3. Make sure that the PCs and/or NASs are properly
connected to the same network as this unit.
4.
Press NETWORK .
5. Select "Music Server" with / (a) on the remote
controller and press ENTER (b).
6. Select the server and music file with / (a) on the
remote controller and press ENTER (b) to confirm. To
return to the previous display, press (c).
0 If "Connection Error." is displayed, check whether the
network is properly connected.
0 Depending on the server being used and the files played,
elapsed play time and remaining play time may not be
displayed.
0 For music files on a server, there can be up to 20,000
tracks per folder, and folders may be nested up to 16
levels deep.
Controlling Remote Playback from a PC
You can use this unit to play music files stored on your PC
by operating the PC inside your home network. The unit
supports remote playback with Windows Media
®
Player 12.
1. Turn on your PC and start Windows Media
®
Player 12.
2. Open the "Stream" menu and check that "Allow remote
control of my Player..." is checked. Click "Turn on media
streaming" to list players in the network.
3. Select and right-click the music file to play with Windows
1
a
b
c
Music Server

Onkyo NS-6130 Specifications

General

Receiver type	Surround
Frequency range	4 - 70000 Hz
Audio output channels	- channels
Signal-to-Noise Ratio (SNR)	112 dB
Total Harmonic Distortion (THD)	0.002 %
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	0
USB ports quantity	2
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
Bluetooth	No
Ethernet LAN	Yes
Supported radio bands	-
Product color	Black
Audio formats supported	AAC, AIFF, FLAC, MP3
Package depth	388 mm
Package width	540 mm
Package height	210 mm
Package weight	5600 g
Cables included	AC
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	22 W

Weight and Dimensions

Depth	317 mm
Width	435 mm
Height	100 mm
Weight	3500 g
