Onkyo T-405X User Manual

32
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 0720-31-8111 Fax: 0720-33-5222 http://www.onkyo-intl.com
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.onkyo.net
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: 852 2429 3118 Fax: 852 2428 9039
E
http://www.onkyo.co.jp/
HOMEPAGE
SN 29342744
Printed in Japan
I9905-1
Specifications
FM
Tuning Range:
87.90 – 107.90 MHz, 200 kHz steps
(U.S. & Canadian models)
87.50 – 108.00 MHz, 50 kHz steps
(Ohter area models)
Usable Sensitivity:
Mono : 12.8 dBf 1.2 µV, 75 Ohms IHF
Stereo: 19.2 dBf 2.5 µV, 75 Ohms IHF
50dB Quieting Sensitivity:
Mono : 18.0 dBf 2.2 µV, 75 Ohms
Stereo: 38.0 dBf 22 µV, 75 Ohms
Capture Ratio : 1.5 dB
Image Rejection Ratio : 85 dB
IF Rejection Ratio : 90 dB
Signal-to-Noise Ratio : Mono: 73 dB IHF
Stereo: 66 dB IHF
Selectivity : 50 dB DIN (±300 kHz, 40 kHz dev.)
AM Suppression Ratio : 50 dB
Total Harmonic Distortion : Mono: 0.5%
Stereo: 0.8%
Frequency Response : 30 – 15,000 Hz (±1.5 dB)
Stereo Separation : 40 dB at 1 kHz
30 dB at 70 – 10,000 Hz
Output Level : 0.5 V (U.S.& Canadian models)
0.75 V (Other area models)
Muting Level : 17.2 dBf 2.0 µV, 75 Ohms
AM
Tuning Range :
530 – 1,710 kHz, 10 kHz steps
Usable Sensitivity : 30 µV
Image Rejection Ratio : 30 dB
IF Rejection Ratio : 40 dB
Signal-to-Noise Ratio : 40 dB
Total Harmonic Distortion : 0.8%
Output Level: 0.15 V
General
Power Supply :
AC 120 V, 60 Hz
AC 230 V, 50 Hz
Power Consumption : 9 W
Dimensions (W × H × D) :
205 × 76 × 279 mm
8-1/16" × 3" × 11"
Weight : 1.7 kg, 3.7 lbs.
AM reception is available only on the U.S. and Canadian
models.
Specifications and external appearance are subject to
change without notice as a result of product improvement.

Onkyo T-405X Specifications

FM Specifications

FM tuning range (U.S. & Canadian models)	87.90 – 107.90 MHz, 200 kHz steps
FM tuning range (Other area models)	87.50 – 108.00 MHz, 50 kHz steps
FM usable sensitivity (Mono)	12.8 dBf 1.2 µV, 75 Ohms IHF
FM usable sensitivity (Stereo)	19.2 dBf 2.5 µV, 75 Ohms IHF
FM 50dB quieting sensitivity (Mono)	18.0 dBf 2.2 µV, 75 Ohms
FM 50dB quieting sensitivity (Stereo)	38.0 dBf 22 µV, 75 Ohms
FM capture ratio	1.5 dB
FM image rejection ratio	85 dB
FM IF rejection ratio	90 dB
FM signal-to-noise ratio (Mono)	73 dB IHF
FM signal-to-noise ratio (Stereo)	66 dB IHF
FM selectivity	50 dB DIN (±300 kHz, 40 kHz dev.)
FM AM suppression ratio	50 dB
FM total harmonic distortion (Mono)	0.5%
FM total harmonic distortion (Stereo)	0.8%
FM frequency response	30 – 15, 000 Hz (±1.5 dB)
FM stereo separation	40 dB at 1 kHz, 30 dB at 70 – 10, 000 Hz
FM output level (U.S. & Canadian models)	0.5 V
FM output level (Other area models)	0.75 V
FM muting level	17.2 dBf 2.0 µV, 75 Ohms

AM Specifications

AM tuning range	530 – 1, 710 kHz, 10 kHz steps
AM usable sensitivity	30 µV
AM image rejection ratio	30 dB
AM IF rejection ratio	40 dB
AM signal-to-noise ratio	40 dB
AM total harmonic distortion	0.8%
AM output level	0.15 V

General Specifications

Power supply (AC 120 V)	60 Hz
Power supply (AC 230 V)	50 Hz
Power consumption	9 W
Dimensions	205 × 76 × 279 mm
Dimensions (inches)	8-1/16" × 3" × 11"
Weight	1.7 kg
Weight (lbs)	3.7 lbs.
