Onkyo TX SR308 User Manual

29
En
Explanatory Notes
Menu HDMI Input
If you connect a video component to an HDMI input, you
must assign that input to an input selector. For example, if
you connect your Blu-ray Disc/DVD player to HDMI
IN 2, you must assign “HDMI2” to the “BD/DVD” input
selector.
Here are the default assignments.
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX, TV/
CD, PORT
` HDMI1, HDMI2, HDMI3:
Select a corresponding HDMI input that the video
component has been connected.
` -----:
Select if you’re not using the HDMI OUT.
Each HDMI input cannot be assigned to two input
selectors or more. When HDMI1 - HDMI3 have
already been assigned, you must set first any unused
input selectors to “-----”, or you will be unable to
assign HDMI1 - HDMI3 to input selector.
Note
•When an HDMI IN is assigned to an input selector as explained
here, the digital audio input for that input selector is automati-
cally set to the same HDMI IN (➔ 29, Digital Audio (Digital
Audio Input)).
• If you connect a component (such as UP-A1 Dock that seated
iPod) to UNIVERSAL PORT jack, you cannot assign any input
to PORT selector.
• Do not assign the component connected with the HDMI input to
TV/CD selector when you set “TV Control” setting to “On”
(➔ 33). Otherwise, appropriate CEC (Consumer Electronics
Control) operation will not be guaranteed.
Menu Component
If you connect a video component to a component video
input, you must assign that input to an input selector. For
example, if you connect your Blu-ray Disc/DVD player to
COMPONENT VIDEO IN 2, you must assign “IN2” to
the “BD/DVD” input selector.
Here are the default assignments.
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX, TV/
CD, PORT
` IN1, IN2:
Select a corresponding component video input that
the video component has been connected.
` -----:
Select if you’re not using the COMPONENT
VIDEO OUT.
Note
• If you connect a component (such as UP-A1 Dock that seated
iPod) to the UNIVERSAL PORT jack, you cannot assign any
input to PORT selector.
Menu Digital Audio
If you connect a component to a digital audio input, you
must assign that input to an input selector. For example, if
you connect your CD player to the OPTICAL IN 1, you
must assign “OPT1” to the “TV/CD” input selector.
Here are the default assignments.
■ BD/DVD, VCR/DVR, CBL/SAT, GAME, AUX, TV/
CD, PORT
` COAX, OPT1, OPT2:
Select a corresponding digital audio input that the
component has been connected.
` -----:
Select if the component is connected to an analog
audio input.
HDMI Input
Input selector Default assignment
BD/DVD HDMI1
VCR/DVR - - - - -
CBL/SAT HDMI2
GAME HDMI3
AUX -----
TV/CD -----
PORT -----
Subwoofer
Ye s
:
No:
Menu Sp Config
b
a
c
a Menu selection
b Setting target
c Setting options (default setting underlined)
Select if a subwoofer is connected.
Select if no subwoofer is connected.
Component (Component Video Input)
Input selector Default assignment
BD/DVD IN1
VCR/DVR - - - - -
CBL/SAT IN2
GAME -----
AUX -----
TV/CD -----
PORT -----
Digital Audio (Digital Audio Input)
Input selector Default assignment
BD/DVD COAX
VCR/DVR - - - - -
CBL/SAT -----
GAME OPT1
AUX -----
TV/CD OPT2
PORT -----

Onkyo TX SR308 Specifications

General

Impedance	6 Ω
Frequency range	20 - 50000 Hz
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Product color	Black
Package depth	537 mm
Package width	416 mm
Package height	268 mm
Dimensions (WxDxH)	435 x 151 x 328 mm
Power requirements	AC 220-230 V, 50/60 Hz
Package weight	10500 g
Power consumption (typical)	310 W

Weight and Dimensions

Weight	8000 g
