31
En
■ Left, Center, Right, Surround Right, Surround
Left, Subwoofer
` Specify the distance from the each speaker to your lis-
tening position.
Note
• The speaker distance setting cannot be changed while a pair of
headphones is connected, or “Audio TV OUT” setting is set to
“On” (➔ 32) or Speakers B is on.
• Speakers that you set to “No” or “None” in the “Sp Config
(Speaker Configuration)” (➔ 30) cannot be selected.
• The Center, Right, and Subwoofer distances can be set up to 5 ft.
(1.5 m) more or less than the Left distance. For example, if the
Left distance is set to 20 ft. (6 m), the Center, Right, and Sub-
woofer distances can be set between 15 and 25 ft. (4.5 and
7.5 m).
• The Surround distances can be set up to 5 ft. (1.5 m) more or
15 ft. (4.5 m) less than the Left distance. For example, if the Left
distance is set to 20 ft. (6 m), the SurrRight and SurrLeft dis-
tances can be set between 5 and 25 ft. (1.5 and 7.5 m).
Menu Level Cal
Here you can adjust the level of each speaker with the
built-in test tone so that the volume of each speaker is the
same at the listening position.
■ Left, Center
*1
, Right, Surround Right, Surround
Left
` –12 dB to 0dB
to +12 dB in 1 dB step.
■ Subwoofer
*1
` –15 dB to 0dB to +12 dB in 1 dB step.
Note
• Speakers that you set to “No” or “None” in the “Sp Config
(Speaker Configuration)” (➔ 30) cannot be selected.
• The speakers cannot be calibrated while a pair of headphones is
connected, Speakers B is on, or “Audio TV OUT” setting is set
to
“On” (➔ 32) or the AV receiver is muted.
*1
For the center speaker and subwoofer, the level settings made
by using AUDIO are saved.
Tip
• If you’re using a handheld sound level meter, adjust the level of
each speaker so that it reads 75 dB SPL at the listening position,
measured with C-weighting and slow reading.
Menu Audio Adjust
With the Audio Adjust functions and settings, you can
adjust the sound and listening modes as you like.
Multiplex/Mono Settings
Multiplex
This setting determines which channel of a stereo multi-
plex source is output. Use it to select audio channels or
languages with multiplex sources, multilingual TV broad-
casts, and so on.
■ Input Ch(Mux)
` Main
:
The main channel is output.
` Sub:
The sub channel is output.
` M/S:
Both the main and sub channels are output.
Mono
This setting specifies the channel to be used for playing
any 2-channel digital source such as Dolby Digital, or 2-
channel analog/PCM source in the Mono listening mode.
■ Input Ch(Mono)
` L+R
:
Both the left and right channels are output.
` Left:
Only the left channel is output.
` Right:
Only the right channel is output.
Dolby Settings
PLII Music (2ch Input)
These settings apply to only 2-channel stereo sources.
■ Panorama
` On:
Panorama function on.
` Off
:
Panorama function off.
With this setting, you can broaden the width of the front
stereo image when using the Dolby Pro Logic II Music
listening mode.
■ Dimension
` –3 to 0
to +3
With this setting, you can move the sound field forward
or backward when using the Dolby Pro Logic II Music
listening mode. Higher settings move the sound field
backward. Lower settings move it forward.
If the stereo image feels too wide, or there’s too much
surround sound, move the sound field forward to
improve the balance. Conversely, if the stereo image
feels like it’s in mono, or there’s not enough surround
sound, move it backward.
■ Center Width
` 0 to 3
to 7
With this setting, you can adjust the width of the sound
from the center speaker when using the Dolby Pro
Logic II Music listening mode. Normally, if you’re
using a center speaker, the center channel sound is out-
put by only the center speaker. (If you’re not using a
center speaker, the center channel sound will be distrib-
uted to the front left and right speakers to create a phan-
tom center). This setting controls the front left, right,
and center mix, allowing you to adjust the weight of the
center channel sound.
Level Cal (Level Calibration)
Audio Adjust
To Next Page
