TX-SR604/604E/8640
PRINTED CIRCUIT BOARD VIEWS-5
TX-SR604/604E/8640
A
1
2
3
4
5
BCDEFGH
U05
FRONT OPT PC BOARD
(NAETC-8789)
Component Side
U06
HEADPHONE JACK PC BOARD
(NAETC-8790)
Component Side
U07
OUTLET TERMINAL PC BOARD
(NAETC-8793)
Component Side
