Onkyo TX-SR607 User Manual

51
Basic Operations
This section explains how to select the input source (i.e., the AV component that you want to listen to or watch).
Selecting the Input Source
1
Use the AV receiver’s input selector buttons to select the input
source.
To select the input source with the remote controller, press the
[RECEIVER] button, and then press the INPUT SELECTOR but-
tons.
2
Start playback on the source component.
When you select DVD or another video component, on your TV, you’ll need
to select the video input that’s connected to the AV receiver’s HDMI OUT,
COMPONENT VIDEO OUT or MONITOR OUT.
On some DVD players, you may need to turn on the digital audio output.
3
To adjust the volume, use the MASTER VOLUME control, or the
remote controller’s VOL [q]/[w] button.
The volume can be set to Min, 1 through 79, or Max.
The AV receiver is designed for home theater enjoyment. It has a wide volume
range, allowing precise adjustment.
4
Select a listening mode and enjoy!
See “Using the Listening Modes” on page 62.
INPUT SELECTOR
MASTER VOLUME
VOL
q/w
INPUT
SELECTOR
RECEIVER
Remote
controller
AV receiver
or
or
AV receiver Remote
controller

Onkyo TX-SR607 Specifications

General

Channels	7.2
HDMI Inputs	4
HDMI Outputs	1
Response Bandwidth	5 Hz - 100 kHz
Signal-To-Noise Ratio	106 dB
THD	0.08%
HD Radio Ready	No
Surround System Class	7.2 channel
HDMI Switching	Yes
Audio D/A Converter	192kHz/24-bit
Video Conversion/Scaling	Yes
HDMI Pass-Through	Yes
Bluetooth	No
Wi-Fi	No
Ethernet	No
USB Port	No
Power Output	90W per channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2 channels driven)
Dolby Technologies	Dolby Digital, Dolby Digital EX, Dolby TrueHD, Dolby Pro Logic IIx
DTS Technologies	DTS-HD Master Audio, DTS Neo:6
Audyssey Technologies	Audyssey Dynamic EQ, Audyssey Dynamic Volume, Audyssey 2EQ
Amplifier Output Details	90 W - 8 Ohm - 20 Hz - 20 kHz - THD 0.08% - 2 channels
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Video Upconversion	Yes
