9
Front & Rear Panels—Continued
The page numbers in parentheses show where you can find the main explanation for each item.
a ON/STANDBY button (38)
This button is used to set the AV receiver to On or
Standby.
b STANDBY indicator (38)
This indicator lights up when the AV receiver is in
Standby mode, and it flashes while a signal is being
received from the remote controller.
c ZONE 2 indicator (87)
This indicator lights up when Zone 2 is selected.
d ZONE 2 LEVEL/TONE LEVEL buttons
ZONE 2 and OFF buttons (87)
The [ZONE 2] button is used to select the input
source for Zone 2.
The [OFF] button is used to turn off the output of
Zone 2.
[–] & [+] buttons (52, 88)
Used to adjust the tone (bass and treble) and the vol-
ume level of Zone 2.
TONE button (52)
Used to select either bass or treble.
e Remote control sensor (13)
This sensor receives control signals from the remote
controller.
f Display
See “Display” on page 10.
g MOVIE/TV button (62)
Selects the listening modes intended for use with
movies and TV.
h MUSIC button (62)
Selects the listening modes intended for use with
music.
i GAME button (62)
Selects the listening modes intended for use with
video games.
j DIMMER or RT/PTY/TP button (52, 57)
This button is used to adjust the display brightness.
On the European model, this is the [RT/PTY/TP]
button, and it’s for RDS (Radio Data System). See
“Using RDS (European models only)” on page 56.
k MEMORY button (55)
This button is used when storing or deleting radio
presets.
l TUNING MODE button (54)
This button is used to select the Auto or Manual
tuning mode.
m DISPLAY button (52)
This button is used to display various information
about the currently selected input source.
n SETUP button
This button is used to access the onscreen setup
menus that appear on the connected TV.
o Arrow, TUNING, PRESET and ENTER
buttons
When the AM or FM input source is selected, the
TUNING [q]/[w] buttons are used to tune the tuner,
and the PRESET [e]/[r] buttons are used to select
radio presets (see page 55).
When the onscreen setup menus are used, they work
as arrow buttons and are used to select and set
items. The [ENTER] button is also used with the
onscreen setup menus.
p RETURN button
This button is used to return to the previously dis-
played onscreen setup menu.
q MASTER VOLUME control (51)
This control is used to adjust the volume of the AV
receiver to Min, 1 through 79 or Max.
r PHONES jack (53)
This 1/4-inch phone jack is for connecting a stan-
dard pair of stereo headphones for private listening.
s AUX INPUT HDMI (24)
Used to connect a HD camcorder etc.
t Input selector buttons (51)
These buttons are used to select from the following
input sources: DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX, TV/TAPE, TUNER, CD, PORT.
u AUX INPUT
This input can be used to connect a camcorder,
game console, and so on. There are jacks for com-
posite video, and analog audio.
PORTABLE (33):
Used to connect a portable Audio Player.
v SETUP MIC jack (46)
The Audyssey 2EQ™ Room Correction and
Speaker Setup microphone connects here.
w PURE AUDIO button and indicator (62)
On models other than the North American / Taiwan
models, selects the Pure Audio listening mode. The
indicator lights up when this mode is selected.
Pressing this button again selects the previous lis-
tening mode.
To Next Page
