PARTS LIST:
NO DESCRIPTION SPEC. Q’TY NO DESCRIPTION SPEC. Q’TY
1 Main Frame 1 71 Bolt M5*12 2
2 Incline Frame 1 72 Bolt M10*45 1
3 Enhance Tube 2 73 Speaker Seal Ring 2
4 Front Roller 1 74 Mp3 Connection Wire 1
5 Rear Roller 1 75 Base Main Frame 1
6 6# Allen Wrench 6mm 1 76 Turnable Sleeve 2
7 5# Allen Wrench 5mm 1 77 Incline Turnable Sleeve 2
8
Allen Wrench With Screw
Driver
S=13, 14, 15 1 78 ARC End Cap 2
9 Side Rail Position Bolt 8 79 Square End Cap 2
10 Motor Bottom Cover 1 80 Left Upright Tube 1
11 Side Rail 2 81 Right Upright Tube 1
12 Left Side Rail End Cap 1 82 Console Main Frame 1
13 Right Side Rail End Cap 1 83 Position Pad 2
14 Left End Cap 1 84 Left Audio Net 1
15 Right End Cap 1 85 Right Audio Net 1
16 Running Belt 1 86 Safety Key Steel Pad 1
17 Driving Belt 1 87 Computer Top Cover 1
18 Motor Top Cover 1 88 Computer Panel 1
19 Rubber Moving Wheel Rubber 2 89 Safety Key 1
20 PU Moving Wheel PU 2 90 Tube Clip 2
21 Cylinder 2 91 Foam Grip 2
22 Magnetic Core
1 92
Left Handle Bar Down
Cover
1
23 Anti-Slip Pad
4 93
Right Handle Bar Down
Cover
1
24 Ring Wire Protector 2 94 Left Computer Cover 1
25 Round Cushion Pad 1 4 95 Right Computer Cover 1
26 Round Cushion Pad 2 2 96 Audio Box Back Cover 2
27 Round Cushion Pad 3 2 97 Handle Bar EVA Cap 4
28 EVA Pad
2 98
Left Bottom Decoration
Case
1
29 AC Motor
1 99
Right Bottom
Decoration Case
1
30 Incline Motor 1 100
Computer Bottom
Cover
1
31 Running Board 1 101 Computer PCB 1
32 Nut M6 16 102 Flat Washer 12 4
33 Nut M10 6 103 Bolt M12*30 2
34 Bolt M8*25 1 104 Nut M8 6
To Next Page
