Orbit T977 User Manual

4
Caution: Read the assembly instruction carefully, and follow the steps of the instruction while
assembling.
When you open the carton, you will find the below spare parts:
ASSEMBLY SPARE PARTS LIST:
NO. DESC. SPEC QTY NO. DESC. SPEC QTY
A MAIN FRAME 1 89 SAFETY KEY 1
B CONSOLE SET 1 92
LEFT HANDLE BOTTOM
COVER
1
6 6#ALLEN WRENCH
6 mm
1 93
RIGHT HANDLE BOTTOM
COVE
1
7 5#ALLEN WRENCH
5 mm
1 98 LEFT BOTTOM COVER 1
8 ALLEN WRENCH WITH DRIVER S=13, 14, 15 1 99 RIGHT BOTTOM COVER 1
54 LOCK WASER 10 14 110 BOLT M10*25 14
80 LEFT UPRIGHT 1 111 SCREW ST4.2*16 10
81 RIGHT UPRIGHT 1
ASSEMBLY TOOLS:
NO. PART DESCRIPTION SPEC. QUAN. (PC)
6 6# ALLEN WRENCH 6mm 1
7 5# ALLEN WRENCH 5mm 1
8
WRENCH W/SCREW
DRIVER
S=13, 14, 15 1
ASSEMBLY INSTRUCTIONS

Orbit T977 Specifications

General

Brand	Orbit
Model	T977
Category	Treadmill
Language	English
