Transport General instructions
cgm.3 system: medium voltage SF
6
gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
2.2.2. l and v modules
Depending on the medium voltage cubicle model, the
accessory box contains some of the following items:
• Ormazabal’s IG-183 General Instructions document
• Actuating lever
• Spring charging lever
• Cubicle connecting kit:
- ormalink
- Springs
- Syntheso grease
- Grounding bar
• End plug kit:
- Cubicle end assembly
- Nylon thread
- Plastic plugs
- Side cover
Figure 2.6. Location of documentation and accessories
