IG-183-EN version 06; 31/03/2020
22
Installation
General instructions
cgm.3 system: medium voltage SF
6
gas-insulated
cubicles up to 38 kV according to IEEE and CSA standards
4. Installation
4.1. Unpacking the equipment
cgm.3 system cubicles come wrapped in protective plastic.
On receiving the equipment, check that the goods supplied
correspond to the order and associated documentation.
The procedure for unpacking the equipment is as follows:
1. Using a blade, cutter or similar tool, cut the cellophane
the cubicle is wrapped in.
It is advisable to cut the cellophane at the rear of the
cubicle or at the corner to avoid scratching the surface.
2. Remove the cellophane.
3. Detach the white polystyrene corner pieces.
4. Unscrew the xings between the base and the pallet.
5. Remove the pallet, handling the cubicle as indicated in
section 2.1.
6. Unpack the documentation and accessories box
located at the bottom rear section or on the roof of the
cubicle, depending on the cubicle model.
7. Remove the self-adhesive protective plastic from the
cable compartment cover.
8. Dispose of any waste in an environmentally-friendly
manner.
It is advisable to make a visual inspection of the equipment
to check whether it has suered any damage in transit. If so,
contact Ormazabal immediately.
The self-adhesive plastic must be removed from the
cable compartment cover so that the equipment
enclosure’s ground connection may have the proper
electrical continuity.
