Page 6
Installation and Operation Manual - Inspire 2000
2. General Information
2.1 Specifications
Combustible Wood
Heating capacity
1
195 m
2
Average peak power– hardwood (Australia) 10.9 kW
Average efficiency – hardwood (Australia) 64 %
Average emissions – hardwood (Australia) 1.1 g/kg
Burn Time
1
6 to 8 hours
Color Metallic black
Flue Spigot Diameter 150 mm
Flue system Triple skin flue system with Deco-Mesh or liner
Minimum Flue Height (from floor protector) 4.6 meters
Maximum Log Length 508 mm sideways
2
Log loading Sideways
Firebox Volume 0,055 m
3
Baffle Material C-Cast
1 Burn time and heating capacity may vary subject to location in home, ue system draft, ue system diameter, locality, heat loss factors, climate,
fuels and other variables.
2 Sideways: through the door you see the sides of the logs.
