(page 38)
Audio Settings
[VOLUME "]: Up
[VOLUME #]: Down
Note:
≥ Press [DISP] (display) to return to the
regular mode.
≥ If no operation takes place for more than
5 seconds in audio setting (2 seconds
in the volume setting, 10 seconds in SQ
adjustment), the display returns to the
regular mode.
≥ The volume can also be adjusted directly
using [VOLUME] on the main unit.
(page 23)
1 Press [VOLUME]
(SEL: select).
Volume
Default:18 Setting range: 0 to 40
Bass/Treble
You can adjust the bass and treble sound.
Default: BAS (bass) 0 dB
TRE (treble) 0 dB
Setting range: j12 dB to i12 dB (by 2 dB)
SQ Adjustment
You can adjust the characteristics of the currently
selected sound type (SQ).
It is also possible for a maximum of 5 different
adjusted SQ to be preset.
Adjustable frequency:
60 Hz, 160 Hz, 400 Hz, 1 kHz, 3 kHz, 6 kHz, 16 kHz
Setting range: j12 dB to i12 dB (by 2 dB)
≥ Setting of SQ, bass/treble and volume are
infl uenced one another. If the infl uence
mentioned above causes distortion to the audio
signal, readjust bass/treble or volume
.
2 Turn [VOLUME].
(Press [VOL "] or [VOL #] on the remote control unit.)
[VOLUME "]: Increased
[VOLUME #]: Decreased
[VOLUME "]: Increased
[VOLUME #]: Decreased
E
N
G
L
I
S
H
17
E
N
G
L
I
S
H
18
(Push.)
Select
Select
Select
Select
[VOLUME "]
[VOLUME #]
[DISP]
(Display)
[SEL]
(Select)
[VOL "]
[VOL #]
1 Press [$] or [%] to select a frequency.
[$]: Increased
[%]: Decreased
2 Turn [VOLUME "#].
[VOLUME "]: Increased
[VOLUME #]: Decreased
3 Press and hold one of the buttons from [2] to [6] for
more than 2 seconds.
≥ The adjusted SQ is preset in the number of
the selected button, and the regular display is
restored.
∫ To return an adjusted SQ to the default setting
1 Press [SQ], and select the SQ which is to be returned
to the default setting.
2 Press and hold [BAND] for more than 2 seconds.
[%] [$]
Note:
≥ Only buttons [2] to [6] can be used to
preset the adjusted SQ. An adjusted SQ
cannot be preset in button [1].
≥ To call a preset SQ, refer to page 25.
≥ While the SQ adjustment mode is
established, only adjustments are
performed, and even if the adjustment
mode is exited without presetting an
adjusted effect, what has been set will be
refl ected as the current SQ until another
SQ is selected.
≥ Even when the SQ presets are adjusted,
the display which appears when the
settings are called remains unchanged.
≥ The SQ adjustment mode can be
established also by pressing [SQ] for
more than 2 seconds.
(SQ adjustment mode)
(Example: Radio mode)
[BAND]
[2] to [6]
(SQ preset
buttons)
To Next Page
