35
• The setting temperature for all the operations can be changed one level up or one level down from the standard temperature as
shown in below table by pressing on the temperature up or temperature down button at remote control.
• The operation mode judging temperature and standard setting temperature can be increased by 2°C permanently, by open the
circuit of JX03 at indoor electronic controller.
12.5. Indoor Fan Speed Control
• Indoor Fan Speed can be set using remote control.
12.5.1. Fan Speed Rotation Chart
Fan Speed (rpm) CS-A7HKD CS-A9HKD CS-A12HKD
S Hi 1200 1310 1320
Hi 1030 1210 1300
Me 920 1000 1120
H Lo 840 890 860
C Lo 780 830 800
Lo- 750 780 750
S Lo 700 750 700
SS Lo 300 300 300
Q S Hi 1100 1210 1220
Q Hi 930 1110 1200
Q Me 820 900 1020
Q H Lo 770 790 810
Q Lo 680 730 700
