Panasonic CS-A9HKD Service Manual

7
2.2. CS-A9HKD CU-A9HKD
Item Unit Indoor unit Outdoor unit
Performance Test Condition NEW JIS
C
Capacity
kW 2.65 - 2.65
O BTU/h 9040 - 9040
O kcal/h 2280 - 2280
L
EER
W/W 3.19 - 3.08
I BTU/hW 10.9 - 10.5
N
Noise Level
dB (A) High: 36 Low: 26 High: 48 - 49
G Power level dB High: 49 High: 63 - 64
H
Capacity
kW 2.80 - 2.85
E BTU/h 9550 - 9720
A kcal/h 2410 - 2450
T
Cop
W/W 4.00 - 3.85
I BTU/hW 13.6 - 13.1
N
Noise Level
dB (A) High: 38 Low: 28 High: 48 - 49
G Power level dB High: 51 High: 64 - 65
Moisture Removal
l/h 1.6
(pt/h) 3.4
Air Volume
Lo
m
3
/m (ft
3
/m)
Cooling; 6.4 (230)
Heating; 6.7 (240)
—
Me
m
3
/m (ft
3
/m)
Cooling; 7.8 (270)
Heating; 7.5 (260)
—
Hi
m
3
/m (ft
3
/m)
Cooling; 9.4 (330)
Heating; 9.8 (350)
Cooling;
29.5 (1040) - 30.0 (1060)
SHi
m
3
/m (ft
3
/m)
Cooling; 10.2 (360) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
—
ATMOS M60 or
SUNISO 4GDID (350cm
3
)
Refrigerant (Charged) R22 kg (oz) — 0.67 (23.7)
Dimension
Height mm (inch) 280 (11 - 1/32) 510 (20 - 3/32)
Width mm (inch) 799 (31 - 15/32) 650 (25 - 19/32)
Depth mm (inch) 183 (7 - 7/32) 230 (9 - 1/16)
Net Weight kg (lbs) 9 (20) 27 (60)
Pipe Diameter
Gas mm (inch) 9.52 (3/8”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 5 (16.4)
Pipe Length Range m (ft) 3 (9.8) ~ 10 (32.8)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner diameter mm 16 —
Length mm 650 —
Compressor
Type —
Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 750
Fan
Type Cross-flow Fan Propeller Fan
Material ASG20K1 PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input power W 42 - 47 56 - 63
Output power W 15 30
Fan Speed
Lo (Cool / Heat) rpm 830 / 890 —
Me (Cool / Heat) rpm 1000 / 1000 —
Hi (Cool / Heat) rpm 1210 / 1310 800 - 830 / —
SHi (Cool / Heat) rpm 1310 / — —
