Panasonic CS-A9HKD Service Manual

74
(Note)
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
REF. NO. PART NAME & DESCRIPTION QTY. CS-A7HKD CS-A9HKD CS-A12HKD
1 CHASSY COMPLETE 1 CWD50C1572 ←←
2 FAN MOTOR, AC 15W SINGLE 1 CWA921373 ←←
3 CROSS FLOW FAN COMPLETE 1 CWH02C1045 ←←
4 BEARING ASS’Y 1 CWH64K007 ←←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ←←
AI ION GENERATOR 1 CWH94C0014 ←←
6 EVAPORATOR CO. 1 CWB30C2416 CWB30C2411 CWB30C2397
7 FLARE NUT (1/4) 1 CWT251026 ←←
8 FLARE NUT (3/8) (1/2) 1 CWT25005 ← CWT25007
A2 E-ION AIR PURIFYING SYSTEM 1 CWH14C5332 ←←
9 CLIP FOR SENSOR 1 CWH32143 ←←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2627 ←←
11 VERTICAL VANE 12 CWE241157 ←←
12 CONNECTING BAR 1 CWE261092 ←←
13 CONNECTING BAR 2 CWE261071 ←←
14 CONNECTING BAR 1 CWE261091 ←←
15 A.S.MOTOR, DC SINGLE 12V300 OHM 1 CWA981091 ←←
17 CAP - DRAIN TRAY 1 CWH521096 ←←
18 HORIZONTAL VANE COMPLETE 1 CWE24C1183 ←←
19 BACK COVER CHASSIS 1 CWD932454 ←←
20 CONTROL BOARD CASING 1 CWH102321 ←←
21 TERMINAL BOARD COMPLETE 1 CWA28C2312 ← CWA28C2313
22 P.S.CORD W/OUT PLUG 1 CWA20C2590 ←←
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2989 CWA73C2991 CWA73C2990
24 ELECTRONIC CONTROLLER - POWER 1 CWA744529 ←←
25 SENSOR COMPLETE 1 CWA50C2122 ← CWA50C2401
26 CONTROL BOARD FRONT COVER 1 CWH131207 ←←
27 INDICATOR COMPLETE 1 CWE39C1183 ←←
28 INDICATOR HOLDER 1 CWD932744 ←←
29 INDICATOR HOLDER 1 CWD932745 ←←
30 CONTROL BOARD TOP COVER 1 CWH13C1171 ←←
31 REMOTE CONTROL COMPLETE 1 CWA75C3173 ←←
32 FRONT GRILLE COMPLETE 1 CWE11C3911 ←←
33 INTAKE GRILLE COMPLETE 1 CWE22C1409 ←←
34 GRILLE DOOR COMPLETE 1 CWE14C1010 ←←
35 E-ION FILTER 2 CWD00K1004 ←←
36 SCREW - FRONT GRILLE 2 XTT4+16CFJ ←←
37 CAP - FRONT GRILLE 2 CWH521109 ←←
38 DRAIN HOSE 1 CWH851063 ←←
39 INSTALLATION PLATE 1 CWH361067 ←←
40 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ←←
41 FULCRUM 1 CWH621049 ←←
