Panasonic LUMIX DMC-GX7P User Manual

62
12 Block Diagram
12.1. Overall Block Diagram
DMC-GX7 OVERALL BLOCK DIAGRAM
MEMORY
CARD
(POWER SUPPLY)
REAR OPERATIONS
IC9901
MOTOR DRIVE
IC7002
BIS MOTOR DRIVE
IC7001,7101,7102,7103
BIS MOTOR DRIVE/
HALL AMP/REF AMP
FLASH
TOP OPERATIONS
IC1001
POWER
AV OUT / DIGITAL
TERMINAL
LENS UNIT
X6001
(24MHz)
LENS CONTACT
TERMINAL
SSWF
SHUTTER
UNIT
BIS YAW BIS PITCH
Q9801, T9801
MOUNT BOX UNIT
IC9102
SYSTEM IC
MICROPHONE AMP
SPEAKER AMP
VIDEO OUT
ECM(R)
ECM(L)
STEREO
MICROPHONE
IC9104
Q8201,8202
QR8201,T8201
HDMI
TERMINAL
SPEAKER
REGULATOR
MOS IMAGE SENSOR
(Built in AFE)
(27MHz)
IC6001
VENUS ENGINE
CAMERA PROCESS
J-PEG COMP/EXPANDS
MEDIA I/F
USB I/F
MAIN MICROPROCESSOR
OIS CONTROL
LENS DRIVE
LCD DRIVE
LP-DDR2 MOBILE RAM /2G-bit
HDMI DRIVER
COLOR LVF
0.38” PANEL
2760k dots
IC1051, 9002
REGULATOR
IC1071
STEP DOWN CONVERTER
IC1081
DC/DC CONVERTER
EXT. FLASH
(OPTION)
QR8001,8002
HOT SHOE
UNIT
REMOTE
TERMINAL
COLOR LCD
PANEL
3.0” PANEL
1040k dots
X9101
(32.768kHz)
TOUCH PANEL
IC9103
REGULATOR
IC6004,6005,
6006,6007,6008
REGULATOR/
LOGIC IC
IC2701
TILT SENSOR
EYE SENSOR
IC9102
SYSTEM IC
IC9402
QR9401
POWER SUPPLY
Q9103
MIC POWER
SUPPLY
IC6003
NOR FLASH ROM/256M-bit
W-LAN MODULE
Wi-Fi
ANTENNA
IC8001
DUAL INTERFACE
RFID
NFC
ANTENNA
UNIT
4/3” 16 MEGA PIX
BATTERY
