Panasonic Lumix DMC-S3 User Manual

10 VQT3E65 VQT3E65 11
Charging the battery
(Continued)
I nserting and removing the card (optional)/
the battery
●
The time required for charging varies depending on conditions of battery usage.
Charging takes longer at high or low temperatures and when the battery has not been
used for some time.
●
Battery will be warm during charging and for some time thereafter.
●
Battery will run out if not used for long periods of time, even after being charged.
●
Charge the battery with the charger indoors (10 °C to 30 °C).
●
Keep any metal items (such as clips) away from the contact areas of the power plug.
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or resulting
heat generated.
●
We do not recommend frequently charging the battery.
(Frequently charging battery reduces maximum usage time and can cause battery to
expand.)
●
Do not disassemble or modify the charger.
●
If available battery power is significantly reduced, battery is reaching end of lifespan.
Please purchase a new battery.
●
The battery charger is in the standby condition when the AC power is supplied.
The primary circuit is always “live” as long as the battery charger is connected to an
electrical outlet.
●
When charging:
• Remove any dirt on connectors of charger and battery with dry cloth.
• Keep at least 1 m (3.28 feet) away from AM radio (may cause radio interference).
• Noises may be emitted from inside of charger, but this is not a fault.
• Remove charger from wall socket after charging (up to 0.1 W consumed if left in
place).
●
Do not use a damaged or dented battery (especially connectors), e.g. by dropping (can
cause faults).
Turn off the power and slide
the card/battery door out ( )
before opening the door (
)
as illustrated
Insert the battery and card,
making sure that their
orientation is correct
• Battery: Insert all the way firmly until
a locking sound is heard,
and check that the lever is
hooked over the battery.
• Card: Insert all the way firmly until it
clicks.
Charged battery (check orientation)
Card ( check orientation:
terminals face LCD)
Do not touch
the terminal
Lever
Close the card/battery door
and slide the door in until
you hear a locking sound

Panasonic Lumix DMC-S3 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	No
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Digital zoom	4 x
Optical zoom	4.7 x
Combined zoom	33.8 x
Focal length range	5 - 20 mm
Lens structure (elements/groups)	6/5
Interface	USB 2.0
Built-in flash	Yes
Camera shutter speed	8 - 1/1600 s
Compatible operating systems	-
Focal length (35mm film equivalent)	28 - 112 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Centre weighted Auto Focus
Auto Mode focusing range (tele)	1 - ∞ m
Auto Mode focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Camera shutter interval	0.9 s
Flash modes	auto, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 1.6 m
Flash range (wide)	0.4 - 3.3 m
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Motion JPEG frame rate	30 fps
Maximum video resolution	1280 x 720 pixels
Analog signal format system	PAL
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Scene modes	Beach, Children, Fireworks, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Slide show
Playback zoom (max)	16 x
Product color	White
Battery capacity	660 mAh
Battery life (CIPA standard)	250 shots
Cables included	USB
Bundled software	PHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader

Weight and Dimensions

Depth	20.9 mm
Width	98.8 mm
Height	58.8 mm
Weight	117 g
