Preset Signals
This unit can display the video signals shown in the table below.
■ Video signal
Corresponding signal Resolution (Dot)
Scanning frequency Dot clock
frequency
(MHz)
Format
*
3
Horizontal (kHz) Vertical (Hz)
NTSC/NTSC4.43/
PAL-M/PAL60
720 × 480i 15.73 59.94 - V
PAL/PAL-N/SECAM 720 × 576i 15.63 50.00 - V
525i(480i) 720 × 480i 15.73 59.94 13.50 R/Y
625i(576i) 720 × 576i 15.63 50.00 13.50 R/Y
525i(480i) 720(1440) × 480i
*
2
15.73 59.94 27.00 D/H
625i(576i) 720(1440) × 576i
*
2
15.63 50.00 27.00 D/H
525p(480p) 720 × 480 31.47 59.94 27.00 R/Y/D/H
625p(576p) 720 × 576 31.25 50.00 27.00 R/Y/D/H
750(720)/60p 1 280 × 720 45.00 60.00 74.25 R/Y/D/H
750(720)/50p 1 280 × 720 37.50 50.00 74.25 R/Y/D/H
1 125(1 080)/60i
*
1
1 920 × 1 080i 33.75 60.00 74.25 R/Y/D/H
1 125(1 080)/50i 1 920 × 1 080i 28.13 50.00 74.25 R/Y/D/H
1 125(1 080)/24p 1 920 × 1 080 27.00 24.00 74.25 R/Y/D/H
1 125(1 080)/24PsF 1 920 × 1 080i 27.00 48.00 74.25 R/Y
1 125(1 080)/25p 1 920 × 1 080 28.13 25.00 74.25 R/Y/D/H
1 125(1 080)/30p 1 920 × 1 080 33.75 30.00 74.25 R/Y/D/H
1 125(1 080)/60p 1 920 × 1 080 67.50 60.00 148.50 R/Y/D/H
1 125(1 080)/50p 1 920 × 1 080 56.25 50.00 148.50 R/Y/D/H
■ PC signal
Corresponding signal Resolution (Dot)
Scanning frequency Dot clock
frequency
(MHz)
Format
*
3
Horizontal (kHz) Vertical (Hz)
640 × 400
640 × 400 31.47 70.09 25.18 R/Y/D/H
640 × 400 37.86 85.08 31.50 R/Y/D/H
640 × 480
640 × 480 31.47 59.94 25.18 R/Y/D/H
640 × 480 35.00 66.67 30.24 R/Y/D/H
640 × 480 37.86 72.81 31.50 R/Y/D/H
640 × 480 37.50 75.00 31.50 R/Y/D/H
640 × 480 43.27 85.01 36.00 R/Y/D/H
800 × 600
800 × 600 35.16 56.25 36.00 R/Y/D/H
800 × 600 37.88 60.32 40.00 R/Y/D/H
800 × 600 48.08 72.19 50.00 R/Y/D/H
800 × 600 46.88 75.00 49.50 R/Y/D/H
800 × 600 53.67 85.06 56.25 R/Y/D/H
832 × 624 832 × 624 49.72 74.55 57.28 R/Y/D/H
852 × 480 852 × 480 31.47 59.94 34.24 D/H
1 024 × 768
1
024 × 768 39.55 50.00 51.89 D/H
1
024 × 768 48.36 60.00 65.00 R/Y/D/H
1
024 × 768 56.48 70.07 75.00 R/Y/D/H
1
024 × 768 60.02 75.03 78.75 R/Y/D/H
1
024 × 768 65.55 81.63 86.00 R/Y/D/H
1
024 × 768 68.68 85.00 94.50 R/Y/D/H
1 066 × 600 1
066 × 600 37.64 59.94 53.00 D/H
1 152 × 864
1
152 × 864 53.70 60.00 81.62 R/Y/D/H
1
152 × 864 63.99 70.02 94.20 R/Y/D/H
1
152 × 864 67.50 75.00 108.00 R/Y/D/H
1
152 × 864 77.09 85.00 119.65 R/Y/D/H
1 152 × 870 1
152 × 870 68.68 75.06 100.00 R/Y/D/H
1 280 × 720 1
280 × 720 44.76 60.00 74.48 R/Y/D/H
1 280 × 768
1
280 × 768 39.55 49.94 65.18 R/Y/D/H
1
280 × 768 47.70 60.00 80.14 R/Y/D/H
1
280 × 768 47.78 59.87 79.50 R/Y/D/H
1 280 × 800
1
280 × 800 41.20 50.00 68.56 R/Y/D/H
1
280 × 800 49.31 59.91 71.00 R/Y/D/H
1
280 × 800 49.70 59.81 83.50 R/Y/D/H
