Panasonic TH-65EF1U User Manual

95
English
Specifications
Model No.
TH-65EF1U
TH-65EF1E
TH-65EF1W
Power Consumption
175 W
Power off condition
0.3 W
Stand-by condition
0.5 W
LCD Display panel
65-inch VA panel (Direct LED backlight), 16:9 aspect
ratio
Screen size
1 428 mm (W) × 803 mm (H) × 1 638 mm (diagonal) /
56.2” (W) × 31.6” (H) × 64.5” (diagonal)
Resolution
2 073 600
(1 920 (Horizontal) × 1 080 (Vertical))
Dimensions (W × H × D)
1 459 mm × 835 mm × 82 mm / 57.5” × 32.9” × 3.3”
Mass
approx. 24.0 / 52.0 lbs net
Power source
TH-65EF1U:
110‒127V~(110‒127Valternatingcurrent),
50/60 Hz
TH-65EF1E, TH-65EF1W:
220‒240V~(220‒240Valternatingcurrent),
50/60 Hz
Operating condition
Temperature
0°C‒40°C(32°F‒104°F)
*
1
Humidity
20%‒80%(nocondensation)
Storing condition
Temperature
-20°C‒60°C(-4°F‒140°F)
Humidity
20%‒80%(nocondensation)
Connection terminals
HDMI 1
HDMI 2
TYPE A Connector
*
2
× 2
Audio signal:
Linear PCM (sampling frequencies - 48 kHz,
44.1 kHz, 32 kHz)
DVI-D IN
DVI-D 24 Pin × 1:
Compliance with DVI Revision 1.0
Content Protection:
Compatible with HDCP 1.1
VIDEO
Audio/Video 4-pole mini jack (M3) × 1
(see page 20)
Video: 1.0 Vp-p (75 Ω)
Audio: 0.5 Vrms
PC IN
Mini D-sub 15 Pin (Compatible with DDC2B) × 1
Y/G:
1.0 Vp-p (75 Ω) (with sync signal)
0.7 Vp-p (75 Ω) (without sync signal)
P
B/CB/B:
0.7 Vp-p (75 Ω) (without sync signal)
P
R/CR/R:
0.7 Vp-p (75 Ω) (without sync signal)
HD/VD:
1.0‒5.0Vp-p(highimpedance)
AUDIO IN
Stereo mini jack (M3) × 1, 0.5 Vrms
Shared with DVI-D IN and PC IN
AUDIO OUT
Stereo mini jack (M3) × 1, 0.5 Vrms
Output:Variable(-∞‒0dB)
(1 kHz 0 dB input, 10 kΩ load)
SERIAL IN
External Control Terminal
D-sub 9 Pin × 1:
RS-232C compatible
LAN
RJ45 × 1:
For network connection, compatible with PJLink
Communication method:
RJ45 10BASE-T/100BASE-TX

Panasonic TH-65EF1U Specifications

General
