EN | Operating manual Transportation, installation and storage
24 WVM 45 -1450
Transport by crane
Transport the adsorption dryer in an upright
position to its location of installation.
Transport by crane
Transport by forklift
When using a forklift, ensure that the dryer is always in an upright position.
Secure the dryer with screws to a pallet to ensure that it cannot tilt or fall from the forklift.
Installation and anchoring of the dryer
Secure dryer by means of suitable securing devices to the oor.
On oscillating oors: The dryer must be positioned on suitable oscillation absorbers.
Storage
If the dryer is not to be installed immediately after delivery, it must be stored at a suitable
location that ful ls the following requirements:
◊ The dryer must not be stored outdoors.
◊ The storage room has to be dry.
◊ The storage room must be free of dust; otherwise, cover dryer with a tarpaulin.
◊ The ambient temperature in the storage room may not be below +1 ºC
To storage the dryer, proceed as follows:
Decommission dryer as described on page 36.
Ensure that the inlet valve and the outlet valve installed on the site are closed and release
all pressure from the dryer.
Make sure that existing steam valves (with optional steam heat exchanger) or cooling
water valves (with optional loop regeneration) are closed.
Disconnect dryer from compressed air system.
Disconnect the plant from the electric mains supply and any external and supply lines.
Cover the following inlet and outlet openings with lm or similar material to protect them
against contamination by dust and dirt:
— inlet and outlet openings for compressed air
— inlet for the regeneration air at the heater
— regeneration air outlet at the vacuum pump
— cooling water intake and exit (with optional loop regeneration)
— hot steam intake (with optional steam heat exchanger)
Cover the dryer with a tarpaulin, if possible..
The dryer is not suitably prepared for prolonged storage.
