PABH 20-Li C3
■ 8
│
GB
│
CY
Changing a tool
■ You can use the SDS-plus tool holder to
change tools quickly and easily without the
need for any additional tools.
■ The SDS-plus drilling tool moves freely
(depending on the system). This leads to a
radial run-out deviation while idling. This has no
effect on the accuracy of the drill hole as the
drill centres itself during drilling.
■ The dust protection cap
largely prevents the
entry of drilling dust into the tool holder
during operation. Ensure that the dust protection
cap does not get damaged when fitting
tools.
NOTE
► A damaged dust protection cap
must be
replaced immediately. We recommend
having this done by a customer service
workshop.
Fitting an SDS tool/quick-release
chuck
WARNING!
►
Do not use the quick-release chuck
for hammer drilling or chiselling!
♦ Before fitting a tool into the tool holder
,
grease it lightly.
♦ Twist the tool into the tool holder
until it clicks
audibly into place.
♦ Check that the tool is properly locked by pulling
it. The system has radial play because of the
design.
Removing an SDS tool
♦ Pull the locking sleeve backwards and
remove the tool.
Operation
Select operating mode
■ Use the “Drill/hammer drill” switch to
select the operating mode of the power tool.
NOTE
► Change the mode only when power tool is
switched off! Otherwise, the tool could be
damaged.
♦ To change the operating mode, turn the “Drill/
hammer drill” switch
to the desired position.
Hammer drilling = Hammer ON
Drilling/screwing = Hammer OFF
Setting the rotation direction
NOTE
► Operate the rotation direction switch
only
when the appliance is at a standstill.
■ You can use the rotation direction switch
to change the direction of rotation of the power
tool. This is not possible, however, while the
On/Off switch is pressed in.
Clockwise
♦ For drilling and screwing in screws, turn the
rotation direction switch
to the left as far
as the stop.
Anticlockwise
♦ For undoing and removing screws and nuts,
turn the rotation direction switch
to the right
as far as the stop.
Switching on/off
Switching on
♦ To start the power tool, press the On/Off
switch
and keep it pressed in.
■ The LED work light
lights up when the On/
Off switch is pushed in slightly or fully and
illuminates the working area in low light condi-
tions.
