Parkside PABS 16 B3 User Manual

Q Torque control
This product is equipped with a torque control that
disengages the spindle when a predefined torque
is exceeded.
o The torque can be adjusted using the torque
sleeve
2
.
o Select a low level for small screws or soft
materials.
o Select a high level for large screws, hard
materials or removing screws.
o Select the drill setting for drilling operation by
turning the torque sleeve
2
to the position .
Q Bit holder
Use the bit holder
4
to store an extra driver bit
for operations that require a frequent change of
the accessories.
Q LED work light
This product is equipped with a LED work light
10
to illuminate the immediate working area to
improve visibility in poorly lit areas.
1. As long as the on-off switch
7
is pressed,
the LED work light
10
is lit and switches off as
soon as the on / off switch is released.
Q Switching on and off
Switching on:
1. Press the on / off switch
7
to switch the
product on. Regulate the speed as required
(see “Speed control”).
Switching off:
1. Release the on / off switch
7
to switch the
product off.
Q After use
1. Switch the product off, remove the battery
pack
8
and let it cool down.
2. Check, clean and store the product as
described below.
Q Tips and tricks
o Before operating the product, check whether
the screw or drill bit is correctly positioned,
i.e. centred in the spindle.
o Screw bits are labelled according to their
dimensions and their shape. If you are
uncertain, always check whether the bit fits
tightly in the screw head without any free play.
Torque
o Smaller screws / bits can be damaged if you
set the torque or rotational speed too high.
Hard screw joints (in metal)
o Particularly high torque occurs, for example in
metal screw joints made using drive sockets.
Select a low rotational speed.
Soft screw joints (e.g. in soft wood)
o Again, use a low rotational speed, e. g. to
avoid damaging the surface of the wood
upon contact with the screw head. Use a
countersink.
Drilling in wood, metal and other materials
o Use a high speed for drill bits with small
diameter and a low speed for drill bits with
large diameter.
o Select a low speed for hard materials and a
high speed for soft materials.
o Secure or fasten the workpiece in a clamp or
vice (if possible).
o Mark the spot where you want to drill using a
centre punch or nail. Select a low rotational
speed when starting.
o Pull the rotating drill bit from the hole
repeatedly to remove dust and chips and
clear the hole.
Drilling in metal
o Use a metal drill (HSS). For optimum results,
cool the drill bit with cooling lubricant (cutting
oil). Metal drill bits can also be used to drill
into plastics. Start with a 3 mm diameter drill
bit and then increase the size until the desired
hole diameter is achieved.
Drilling in wood
o Use a wood drill with a lathe centre; for deep
holes, use an auger bit; for large-diameter
holes, use a Forstner bit. Small screws can be
screwed directly into soft wood.
13 GB / IE / NI / CY
