Parkside PHSHE 900 A1 User Manual

22
GB
IE
NI
Turning the blade bar
1. Switch the device off and remove the
mains plug.
2. Release the nut (
26) and remove the
chain wheel cover (
27).
3. Remove the chain wheel cover (
20)
and the blade bar (
28).
4. Turn the blade bar (
28) once along
its horizontal axis.
5. Insert the saw chain (
20) into the
blade bar groove. To assemble, hold
the blade bar (
28) tilted upwards at
an angle of approx. 45 degrees in or-
der to be able to guide the saw chain
(
20) more easily onto the chain
sprocket (
29).
6. Place the blade bar (
28) and saw
chain (
20) onto the rail bolts (
30). When the nose on the right below
the guide bolt (
30) sits in the lower
round recess on the blade bar, the bla-
de bar is placed correctly. It is normal
for the saw chain (
20) to sag.
7. Pre-tension the saw chain (
20) by
turning the screw (
31) to tension the
chain in a clockwise direction.
8. Put the chain wheel cover (
27) back
in position. Tighten the chain wheel co-
ver nut (
26).
Storage
• Store the device in the protective cover (
A
18/19) provided in a dry location
and out of reach of children.
• You can hang up the device for storage
using the handgrip for adjusting the cut-
ter bar (
A
1).
• Empty the oil tank if it will not be used for
a prolonged period of time (6-8 weeks).
Transport
Never transport your appli-
ance while the appliance is
turned on! Risk of injury!
• Always use the protective
cover (
A
18/19) when transporting.
• Always carry the device with the cut-
ting unit pointing backwards using both
hands: one on the rear handle and the
other on the front round handle (
A
10).
Waste Disposal
and Environmental
Protection
Be environmentally friendly. Return the tool,
accessories and packaging to a recycling

Do not dispose of waste oil in the sewer or
your drain system. Dispose of waste oil in
an environmentally friendly way - take it to
your local recycling centre.
Electrical machines do not belong in
domestic waste.
Take the equipment to a waste disposal
site. The plastic and metal parts that are
used can be separated out into pure grade,
which allows recycling. Ask our Service
Centre for details.
