Intended use
This product is suitable for measuring distances, lengths and
heights in indoor spaces. Any other use or product modification
shall be considered improper use and hold considerable safety
hazards. The manufacturer assumes no liability for damages
due to improper use. Not intended for commercial use.
Parts description
1
Receiver lens
2
Laser beam output opening
3
Display
4
MEAS button (Switch on and off, selection of measure-
ment unit, activation of laser beam for measuring lengths)
5
Battery compartment cover
6
Battery compartment
Display
7
Laser on
8
Battery charge level display
9
First (previous) measured value
10
Length unit
11
Second (latest) measured value
12
Reference plane
12 a
The measurement is taken from the top side of the product
12 b
The measurement is taken from the bottom side of the
product
Note: First (previous) measured value will move to the top
row when the second (latest) measurement is successfully
completed.
