6
GB IE CY
General description
The illustration of the principal
functioning parts can be found
on the front and back foldout
pages.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete.
The appliance is supplied with the motor
head tted ( 3). To remove the motor
head, open the sealing clips ( 5).
Dispose of the packaging material cor-
rectly.
3 Motor housing
6 Container
8 5 castors
14 Folded lter
15 Paper lter bag
16 Foam lter
17 Accessory bag
18 Handle with air regulation
19 Telescopic suction tube
21 Vacuum hose
22 Powertool hose
23 Powertool reduction adaptor
piece
24 Ground nozzle for dry
vacuuming
25 Ground nozzle for wet
vacuuming
26 Crevice nozzle
27 Cushion nozzle
28 Car nozzle
29 2 retaining brackets
8b 5 cross recessed screws
- Instruction Manual
Overview
Housing
1 Carrying handle
2 Filter cleaning button
3 Motor housing with accessory
tting (3a)
4 Air ow control
5 Sealing clip
6 Container
7 Mains power cable
8 5 castors with accessory
holders (8a)
9 Drainage outlet
10 Suction connection
11 Appliance socket
12 Blow connection
13 On/off switch
Filter
14 Folded lter for dry vacuuming
(already tted)
14a Cover plate (not visible)
15 Paper lter bag for vacuuming
large dirt particles
16 Foam lter (wet lter) for wet
vacuuming
Accessories
17 Accessory bag
18 Handle with air regulation
19 Telescopic suction tube
20 Vacuum tube holder
21 Vacuum hose with catch (21a)
22 Powertool hose
23 Powertool reduction adaptor
piece for connecting electrical
equipment for dust extraction.
