10 GB
Do not use the maximum/minimum length
levers [] [] routinely as a stop mechanism.
These levers serve as a stop mechanism only
in emergencies.
Before you begin: Check whether
– the steel cable [] is wound properly
around the drum [] and whether
– the space between coils is less than the
diameter of the cable itself (Fig. D).
Before first use
Remove the packaging materials.
Remove the transport lock from the steel cable
[]. Cut the rubber band and remove it.
Before you begin: Check whether
– the steel cable [] is wound properly
around the drum [] and whether
– the space between coils is less than the
diameter of the cable itself (Fig. D).
Make sure the steel cable [] passes the
maximum/minimum length levers [] []
properly and without touching them (Fig. B).
Assembly
(Fig. E)
m
DANGER!
u The square tube (cross sectional
dimensions: 45 x 45 mm) must be able
to bear a minimum load of 500 kg at
the points where the product is fastened.
It is recommended to consult qualified
personnel (for example a structural
engineer) for assembly.
u Because special knowledge is required,
seek advice from a qualified technician to
ensure all screws are tightened fully and
correctly.
u A qualified technician or a properly trained
person should also check the anchoring
of the square tube before the product is
fastened.
u Time needed for assembly: approx. 1 hour
Fasten the product with the mounting brackets
[1] and the mounting screws [2] to a suitable
square tube.
Tighten the mounting screws [2].
Operation
NOTE
u The product has been outfitted with a
thermostat switch. During operation, it may
stop the motor [3]. The motor can be only
started again once it has cooled down.
