12 GB
Hang the pulley [] in the loop formed by the
steel cable [] (Fig. G).
Attach the screws and the extra hook [] to
the pulley []. Fasten the 3 screws (Fig. H).
The block and tackle is now operational
(Fig. I).
Cleaning and care
m
WARNING!
Disconnect the device from the power supply
before inspections, maintenance or cleaning!
Cleaning
Ensure that no water enters the product
interior.
Regular, proper cleaning helps ensure safe
operation and lengthens the service life of
your product.
Clean the product with a dry cloth. Use a soft
brush for hard-to-reach areas.
NOTE
u Do not use any chemical, alkaline, abrasive
or otherwise aggressive cleaning or
disinfecting agents to clean the product as
they may damage its surfaces.
Maintenance
Test interval Procedure
Before each use Check whether the emergency
off switch [7] and control
switch [8] are properly
functioning.
Every 30 cycles* Check the entire steel cable
[
]
for damages (Fig. K).
Replace the steel cable
if damaged (available at
specialist retailers).
Every 100 cycles* Check to ensure the
maximum/minimum length
levers [
]
[
]
are fully
functional without load.
Every 200 cycles*
Lubricate the steel cable [
]
and the pulley [
]
.
Every 800 cycles* Make sure all screws are
securely fastened.
Check the entire product for
signs of wear.
* One cycle corresponds to one upward and
downward movement of a load.
Repairs
There are no parts in the product interior that
can be repaired by the user. Contact a qualified
professional to have the product checked and
repaired.
