8
INTELLIFLO
®
2 VST Variable Speed Pump Installation and User’s Guide
Pump Menu: Settings
Pump Address
The default pump address is #1 and only needs to be
changed when there is more than one pump on an
automation system. Change the address to allow the
automation system to send a command to the correct
pump.
Use this setting if your pump is connected via the RS-485
COM port to an IntelliTouch
®
, EasyTouch
®
, SunTouch
®
Control System or IntelliComm
®
Communication Center.
For EasyTouch, SunTouch or IntelliComm systems, the
pump only communicates with address #1. The pump
address can be set from 1-16. The IntelliTouch
system
can communicate to only four (1-4) pumps.
Note: IntelliFlo 2 VST pumps cannot be connected in
series with other pumps.
1. Be sure the green power LED is on and the pump is
stopped.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Device” and
press Select.
Set Date and Time
The time controls all scheduled times, functions, and
programmed cycles and stores the correct time for up
to 96 hours after power is turned off. Reset if the power
is off longer than 96 hours.
1. Check that the green power LED is on.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Date and
Time” and press Select.
5. Press Select again and use Up or Down arrows to
set the date.
6. Press Save to save user input and return to "Date
and Time."
7. Use the Up or Down arrows to scroll to “Time” and
press Select.
8. Use the Up or Down arrows to scroll to set the time.
Note: To set AM/PM or a 24 hour clock see the next
section "Set AM/PM or 24 Hour Clock."
9. Press Save to save. To cancel any changes, press
Back to exit without saving.
10. Press Back to exit.
Set AM/PM or 24 Hour Clock
To change the time from a 12 hour clock (AM/PM) to a
24 hour clock:
1. Press Menu.
2. Press Select to select “Settings”.
3. Use the Up or Down arrows to scroll to “Date and
Time" and press Select.
4. Use the Up or Down arrows to scroll to "AM/PM"
and press Select.
5. Use the Up or Down arrows to scroll to choose
between 24 hr. and AM/PM.
6. Press Save to save. To cancel any changes, press
Back to exit without saving.
7. Press Back to exit.
MENU
SETTINGS
Set Maximum Speed (RPM)
The maximum speed can be set from 1900 RPM to 3450
RPM (default is 3450). Use this setting to set the maximum
running speed of the IntelliFlo
®
2 VST Variable Speed Pump.
1. Check that the green power LED is on.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Min/Max”.
5. Use the Up or Down arrows to scroll to “Set Max Spd”.
6. Press Select to change. The cursor will appear in the
first number column (ones).
7. Press Up or Down arrows to change the maximum
speed setting from 1900 to 3450 RPM.
8. Press Save to save. Press Back to exit. To cancel, press
the Back to exit without saving.
7. Press the Up or Down arrows to change the minimum
speed setting from 450 to 1700 RPM.
8. Press Save to save. To cancel, press Back to exit edit
mode without saving.
9. Press Back to exit.
Set Minimum Speed (RPM)
The minimum pump speed can be set from 450 RPM
to 1700 RPM. The default setting is 450 RPM.
1. Check that the green power LED is on.
2. Press Menu.
3. Press Select to select “Settings”.
4. Use the Up or Down arrows to scroll to “Min/Max”.
5. Use the Up or Down arrows to scroll to “Set Min Spd”.
6. Press Select to change the setting. The cursor will
appear in the first number column (ones).
Note: Maximum Speed will limit Priming Speed, except
in one case. If the Maximum Speed is set below the
lowest available Priming Speed (2400 RPM) then the
pump will exceed the Maximum Speed while the priming
feature is running. This prevents the pump from having
trouble priming if the Maximum Speed is set this low. If
this is a problem, priming can be disabled in the Priming
Menu (see “Priming” section on page 13).
