Performax 241-0502 User Manual

30
Key #
Part #
Part Name
Quantity
21
2010240003
Limit position ring
1
22
2010090007
Gearing ring
1
23
2010010009
Planetary gear
3
24
2030020007
Washer
1
25
3150080002
H/L speed gear box
1
26
4030010029
Tapping screw
4
27
4030010029
Planetary carrier
1
28
2010010008
Planetary gear
3
29
1170070006
Planetary carrier
1
30
1170070006
Moveable ring gear
1
31
2010010012
Planetary gear
3
32
2010010012
Timing point ring
1
33
2050080037
2-speed lever
1
34
2010090010
Fixed ring gear
1
35
2010090010
Washer
1
36
2030020006
Motor gear
1
37
2010180003
Screw
2
38
4020010028
Motor flange
1
39
3150090003
Motor assembly
1
40
3120030024
FWD/REV lever
1
41
3120030024
PCB
1
42
1130050007
Switch assembly
1
43
1060190001
Contact plate
1
44
3120120102
Speed selector button
1
45
2050070002
Lever
1
46
2050070002
LED lens
1
47
3160060024
Left housing
1
48
2030030083
Clip
1
49
4030010031
Tapping screw
5
50
3010010147
Right housing
1
51
4030010012
Tapping screw
2
52
1070060003
Battery pack
1
PARTS LIST
