Tools Required
Return to Table of Contents
STEP 2.
Remove door gasket carefully starting at the
corners and avoid ripping the dart.
STEP 3.
STEP 4.
Residential Refrigeration
and Front Venting Commercial Refrigeration
Service Manual
Custom Overlay Panels
9.9.1 Overlay Panel Installation
STEP 1.
Wood overlay install ready.
In some cases, the dart on the gasket may rip. If
this happens, replace with a new gasket.
Gasket removed. This should reveal the
necessary screw holes needed to hold the
overlay panel.
Replacement Parts Page 9-8
