Controls
7 - 1
7.02 Keys on the machine head
● The following functions are triggered by
pressing the respective key.
Key 1: reverse sewing
Key 2: prevention or release of the
automatic start back tack or finish
back tack.
Key 3: when sewing is interrupted, the
needle can either be raised or
lowered as required.
7 Controls
7.01 On/Off switch
● Turn the machine on/off by pressing the
On/Off switch 1.
● With the buttons 2 the parameters, such
as back-tacking function, raising the
presser foot, needle position at sewing
stop etc., can be pre-selected (also see
the Motor Instruction Manual).
Fig. 7 - 01
Fig. 7 - 02
1
2
2
3
1
