7:3
Maintenance
Changing the light bulb
Switch off the main switch.
• Disconnect the lead cord and the foot control plug from
the machine.
• Remove the accessory tray. The light bulb is located
inside the sewing machine near the needle threader.
Bulb removal
Push the bulb remover, as shown in the À gure, up as far as it
will go. Now turn the bulb half a rotation counterclockwise
and remove the bulb.
Insertion of the bulb
Insert the bulb in the lamp changer. Guide the bulb into the
diagonal holder and turn it until the pins of the bulb engage.
Push the bulb upward into the holder as far as it will go and
turn it half a rotation in a clockwise direction. Remove the
bulb changer from the bulb, the bulb is held À rmly.
Important: The maximum wattage of the bulb is 5 watts.
Bulbs can be purchased from your PFAFF dealer.
