Phanteks eclipse p400 User Manual

17
3.5” INSTALLATION 2.5” INSTALLATION
11. HARD DRIVE INSTALLATION
Slide in the SSD and screw in from the side to lock in place.
将SSD滑入支架后并在支架侧面锁入螺丝固定。
SSD を挿入し、側面からねじで留め、固定します
SSD 밀어 제자리에 고정합니다 측면에서의 나사.
Вставьте кронштейн SSD в паз и закрутите сбоку.
Place hard drive into tray and push in the arms to lock.
把硬盘放入托盘，并推入两边侧翼锁住。
ハードドライブをトレイに置き、アームを押して固定します。하
드 드라이브를 트레이에 넣고 암을 안쪽으로 눌러 고정합니다.
Установите жесткий диск в лоток и нажмите на рычажки для
фиксации.

Phanteks eclipse p400 Specifications

General

Type	PC
Material	Acrylonitrile butadiene styrene (ABS), Steel
Form factor	Midi Tower
Illumination	Yes
Product color	White
Illumination color	Blue
Maximum PSU length	270 mm
Number of 2.5\" bays	2
Number of 3.5\" bays	6
Illumination location	Front
Number of 5.25\" bays	0
Maximum CPU cooler height	160 mm
Number of expansion slots	7
Maximum graphics card length	395 mm
Supported motherboard form factors	ATX, EATX, Micro ATX, Mini-ITX
Supported HDD sizes	2.5, 3.5 \
Power supply included	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Front fans installed	1x 120 mm
Rear fans diameters supported	120 mm
Front fans diameters supported	120, 140 mm
Front radiator sizes supported	140, 200, 240, 280, 360 mm
Number of rear fans supported (max)	1
Number of front fans supported (max)	3
Package depth	520 mm
Package width	300 mm
Package height	555 mm
Package weight	8000 g

Weight and Dimensions

Depth	470 mm
Width	210 mm
Height	465 mm
Weight	7000 g
