Revision List
EN 2 Q543.1E LA1.
2009-Nov-20
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• All Chapters: added 37PFL5604H/60, 47PFL5604/60,
52PFL5604H/12 and 52PFL5604H/60 to the manual
• Chapter 2: added AV output characteristics to section
2.3.2 Rear Connections
• Chapter 6: changed option codes of all sets,
see Table 6-4
• Chapter 7: extended flash memory (PNX5100) to 1 GB,
see Figure 7-1
.
Manual xxxx xxx xxxx.2
• All Chapters: added 32PFL3904H/12 to the manual
• Chapter 5: changed SSB replacement flowchart diagram,
see section 5.8.12
• Chapter 6: changed option code of 32PFL5404H/xx,
see Table 6-4
• Chapter 10: added SSB version 3 (v3) to version 1 (v1)
schematics. Version is indicated on SSB with “.3”
respectively “.1”.
Delta’s with .1:
Provision for temperature sensor connectivity:
- connectors 1M71, 1FA1 and 1FA2 (not stuffed)
- ICs 7FA1 and 7FA3 (not stuffed)
Provision for additional USB connectivity:
- connector 1M10 (not stuffed)
Provision for additional ethernet connectivity:
- IC 7N04 (McPhyter) (not stuffed).
2. Technical Specifications and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model numbers
2.2 Directions for Use
You can download this information from the following websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN Styling Published in:
32PFL3904H/12
P & S 3122 785 18542
32PFL5404H/12
3122 785 18540
37PFL5604H/12
3122 785 18540
37PFL5604H/60
3122 785 18541
47PFL5604H/12
3122 785 18540
47PFL5604H/60
3122 785 18541
52PFL5604H/12
3122 785 18541
52PFL5604H/60
3122 785 18541

Philips 32PFL5404H/12 Specifications

Picture and Display

aspect ratio	Widescreen
brightness	450 cd/m²
response time	5 ms
viewing angle	178º (H)/178º (V)
diagonal screen size	32 inch / 81 cm
panel resolution	1366 x 768p

Supported Display Resolutions

computer formats	640 x 480 60 Hz, 800 x 600 60 Hz, 1024 x 768 60 Hz, 1360 x 768 60 Hz, 1920 x 1080 60 Hz
video formats	480i 60 Hz, 480p 60 Hz, 576i 50 Hz, 576p 50 Hz, 720p 50, 60 Hz, 1080i 50, 60 Hz, 1080p 24, 50, 60 Hz, 1080p 24, 25, 30 Hz

Sound

output power (RMS)	2 x 10 W
sound system	Nicam Stereo

Power

ambient temperature	5°C to 35°C
mains power	220–240 V, 50 Hz
power consumption (typical)	83 W
standby power consumption	0.15 W

Weight and Dimensions

set dimensions	810 x 519 x 95 mm
set dimensions with stand	810 x 570 x 230 mm
weight including packaging	16 kg
product weight	10 kg
product weight with stand	13 kg
box dimensions	981 x 651 x 199 mm
VESA wall mount compatible	200 x 200 mm
