Accessibility
1
Press x (HOME) and use H I J K to select Settings then press
OK.
2
Use H I to select Accessibility, then press OK.
3
Adjust the following items.
Caption (Cable/Antenna)
Display
Off Closed caption is not displayed.
On
Closed caption is always
displayed.
CC w/ mute
Closed caption is displayed
when the sound is off.
Caption service
CC-1 and
T-1
The primary closed captions and
text services. The closed captions
or text is displayed in the same
language as the program’s dialog
(up to 4 lines of script on the TV
screen).
CC-3 and
T-3
Serve as the preferred data
channels. The closed captions or
text is often a secondary
language.
CC-2, CC-4,
T-2 and T-4
Rarely available and
broadcasters use them only in
special conditions, such as when
CC-1 and CC-3 or T-1 and T-3 are
not available.
In addition to the basic closed caption, DTV has its own closed caption
called digital caption service. Use this menu to change the settings for
digital caption service.
Advanced
selection
CS-1 to
CS-6
Select one of these before
changing any other item in
Caption (Cable/Antenna) menu.
Choose CS-1 under normal
conditions.
Caption (Streaming & Other content)
Display
Off Closed caption is not displayed.
On
Closed caption is always
displayed.
You can choose the size, font, color, background and other
characteristics of the caption text.
Language
¡ Default
¡ English
¡ Español
¡ Français
Text size
¡ Very small
¡ Small
¡ Normal
¡ Large
¡ Very large
Picture display
Text font
(Font family, Text size, Text color and Text opacity)
Text edge
(Edge color and Edge type)
Background
(Background color and Background opacity)
Review your setting choice made above by looking in the bottom
left corner of the displayed setting box (not all selections show the
differences selected).
29
.English
Continued on next page.

Other manuals for Philips 55PFL5604

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PFL5604 and is the answer not in the manual?

Philips 55PFL5604 Specifications

General IconGeneral
Screen shapeFlat
Response time16 ms
Display diagonal54.6 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Supported video modes480i, 480p, 720p, 1080i, 1080p, 2160p
Contrast ratio (typical)1000:1
Display diagonal (metric)139.7 cm
Screen format adjustments4:3, 16:9
Supported graphics resolutions640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
Motion interpolation technology-
RMS rated power20 W
Number of speakers2
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)135 W
Product colorBlack
Panel mounting interface300 x 300 mm
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version4.2
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Operating system versionOreo
Operating system installedAndroid
3DNo
Quantity per pack1 pc(s)
Network streaming services supportedChromecast
Tuner typeAnalog & digital
Supported TV bandsUHF, VHF
Analog signal format systemNTSC
Digital signal format systemATSC
Audio (L/R) in1
HDMI ports quantity3
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in0
Consumer Electronics Control (CEC)EasyLink
Operating temperature (T-T)5 - 40 °C
Cables includedAC
Package depth152.4 mm
Package width1412.24 mm
Package height810.26 mm
Package weight15399.46 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)223.52 mm
Height (with stand)751.84 mm
Weight (with stand)10500.66 g
Depth (without stand)78.74 mm
Width (without stand)1249.68 mm
Height (without stand)723.9 mm
Weight (without stand)10400.87 g
