Philips EasyKey Alpha Series User Manual

8
8 9
10
After xing the
striker, please
test if the door
can be opened
and closed
smoothly.
Tighten the M6
chamfer head
screws and the 2 M4
hexagon screws.
M6 Chamfer
Head Screws
M4 Hexagon
Screws
Put in the batteries
and close the
battery cover.
Then x the
striker to nish
the installation.
Please check if all
components are
connected properly,
such as the push-
pull handle, the safe
handle switch and
the mechanical key.
6
7
Please hide the extra
connecting wires into
the hole of the door.
Install the compressed spring
and square shaft into the
inside escutcheon accordingly.
Insert the connection wire of the
outside escutcheon and the motor
wire into the corresponding holes on
the inside escutcheon,
then align the square
shaft on the inside
escutcheon with the
rotary hole on the
mortise and insert
it to make sure the
inside escutcheon
is kept close to the
inside of the door.
Attention
Attention
