1.2 Diagnostics via object 0018
hex
(DiagState)
In addition, each I/O module is equipped with object 0018
hex
(DiagState) that serves the
structured reporting of an error. The I/O module also makes its diagnostics state available.
The object is illustrated in the module-specific documentation of each I/O module.
Table 1-1 Diagnostics state (0018
hex
: DiagState) (general representation)
0018
hex
: DiagState (Read)
Subindex Data type Length in
bytes
Meaning Content
0 Record 6 entries Diagnostic state Complete diagnostic information
1 Unsigned 16 2 Error number Unique, consecutive number since the last
power-up reset or the last reset of the diagnos-
tics counter
0 ... 65535
dec
2 Unsigned 8 1 Priority 00
hex
No error
01
hex
Error
02
hex
Warning
03
hex
Information
81
hex
Error eliminated
82
hex
Warning eliminated
83
hex
Information eliminated
3 Unsigned 8 1 Channel/group/mod-
ule
Channel, group or module where the error oc-
curred.
Additional information under “Additional infor-
mation”.
00
hex
No error
xx
hex
Channel xx, groupxx or module xx
FF
hex
Entire device
4 Unsigned 16 2 Error code Error code
5 Unsigned 8 1 Additional Information 00
hex
Subindex 3 refers to a channel
number.
04
hex
Subindex 3 refers to a group num-
ber.
08
hex
Subindex 3 refers to a module
number.
Other Currently not used.
6 Visible string max. 51 Text Plain text message of the error
