UM EN AXL F SYS DIAG
28
PHOENIX CONTACT 8663_en_03
2.4 Error codes of the I/O modules
If there is an error on an I/O module, the module reports this error to the local bus master.
Please refer to the module-specific data sheets for the error types that a module reports.
Table 2-5 Error codes of the I/O modules
Code
(hex)
Meaning Remedy
0000 No error
1000 General fault
2000 Current
2130 Short circuit Check the wiring.
Overload of the analog output or short circuit
2211 Overload at an input
Sensor supply overload for the inputs
2344 Overload at an output
Short circuit/overload of an output
2345 Sensor supply overload
3000 Voltage
3300 Output voltage
Short circuit or overload at the output
3400 I/O supply voltage failure Check the I/O supply.
3412 Sensor supply not present
I/O supply voltage failure
3422 Actuator supply not present
4000 Temperature
5000 Device hardware
5112 Faulty 24 V supply Check the I/O supply.
Short circuit or overload at the 24 V supply
24 V encoder supply for channel x faulty
5113 Short circuit or overload of the 5 V supply
5120 Cold junction invalid Check the cold junction.
5160 Supply voltage faulty Check the I/O supply.
I/O supply overload
