PIAGGIO Beverly Tourer 250 i.e. User Manual

Brakes
FRENI
Specification Desc./Quantity
Front brake Ø 260-mm disc brake with hydraulic control activated by han-
dlebar right lever.
Rear brake Ø 260-mm disc brake with hydraulic control activated by han-
dlebar left lever.
Wheels and tyres
RUOTE E PNEUMATICI
Specification Desc./Quantity
Wheel rim type Light alloy rims.
Front rim 16'' x 3.00
Rear rim 16 x 3.50''
Front tyre Tubeless, 110/70 - 16'' 52P
Rear tyre Tubeless, 140/70 - 16'' 65P
Front tyre pressure (with passenger) 2 bar (-)
Rear tyre pressure (with passenger) 2.5 bar (-)
N.B.
CHECK AND ADJUST TYRE PRESSURE WITH TYRES AT AMBIENT TEMPERATURE. REGU-
LATE PRESSURE ACCORDING TO THE WEIGHT OF THE RIDER AND ACCESSORIES
Tightening Torques
STEERING
Name
Torque in Nm
Upper steering ring nut 30 ÷ 36
Steering lower ring nut 10 ÷ 13 then loosen by 90°
Handlebar fixing screw (*) 45 ÷ 50
Fixing screws for handlebar control assembly U-bolts 7 ÷ 10
CHASSIS
Name
Torque in Nm
Centre stand bolt 25 ÷ 30
Side stand bolt (°) 35 ÷ 40
Engine arm bolt - frame arm 33 ÷ 41
Swinging arm buffer nut 64 - 72
Frame-swinging arm bolt 64 - 72
Engine-swinging arm bolt 64 - 72
FRONT SUSPENSION
Name
Torque in Nm
Fixing screw for pumping elements to lower fork plate 20 ÷ 25
Front wheel axle 45 ÷ 50
Fork leg screw 6 ÷ 7
front mudguard to plate fixing screw 4.5 ÷ 7
Fixing screw for mudguard plate to fork 9 ÷ 11
REAR SUSPENSION
Name
Torque in Nm
Upper shock absorber clamp 33 ÷ 41
Lower shock absorber clamp 33 ÷ 41
Shock absorber-crankcase attachment bracket 20 ÷ 25
Rear wheel axle 104 ÷ 126
Fixing screw for wheel rim to hub 34 ÷ 38
Beverly Tourer 250 i.e. Characteristics
CHAR - 11
