5. Screw on and tighten part 5 to the prescribed
torque
6. Tighten part 1 to the prescribed torque
Insert the swinging arm - engine bolt and tighten
to the prescribed torque
SWINGING ARM FITTING
Name
Torque in Nm
Part 1 64 ÷ 72 Nm
Part 3 5 - 7 Nm
Part 4 90 ÷ 110 Nm
Part 5 64 ÷ 72 Nm
Engine-swinging arm bolt 64 - 72
Beverly Tourer 250 i.e. Suspensions
SUSP - 223
