PIAGGIO Beverly Tourer 250 i.e. - Removal; Refitting; Rear brake disc

Removal
- Remove the two retainers fastening the front
brake calliper to the support as shown in the pho-
tograph.
N.B.
SHOULD IT BE NECESSARY TO REPLACE THE CALLIP-
ER, FIRST LOOSEN THE FITTING CONNECTING THE PIPE
TO THE BRAKE CALLIPER.
Refitting
- To fit the calliper, follow the above operations but in reverse order.
Locking torques (N*m)
Screw tightening calliper to the support 20 ÷ 25
If the calliper is replaced:
CAUTION
ALWAYS USE NEW COPPER WASHERS.
CAUTION
ONCE REFITTING IS FINISHED, BLEED THE SYSTEM.
Locking torques (N*m)
Brake fluid tube-calliper fitting 20 ÷ 25
See also
Front
Rear brake disc
Removal
- Remove the rear wheel.
- Act on the disc five fixing screws shown in the
photograph.
See also
Removing the rear wheel
Braking system Beverly Tourer 250 i.e.
BRAK SYS - 230
