PIAGGIO Beverly Tourer 250 i.e. User Manual

Frame central cover
Side fairings
- Remove the saddle.
- Remove the luggage rack.
- Remove the central cover.
- Remove the rear light assembly.
- Remove the cover under the saddle by loosening
the retaining screw located under the saddle
mounting plate.
- Loosen the 6 side-fairing fixing screws indicated
in the 3 photographs.
- Remove the fairings.
See also
Taillight assy.
Rear rack
Frame central cover
Seat
Chassis Beverly Tourer 250 i.e.
CHAS - 254
