CAUTION
BRAKING SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE.
03_38
Rear drum brake (03_38)
Operate adjusting nut «B» and loosen lock nut «A» shown in the figure. Note that
when the throttle is in idle the wheel should rotate free. After the adjustment, screw
lock nut «A».
CAUTION
BRAKING SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE.
03_39
Puncture (03_39)
The vehicle is equipped with Tubeless tyres. When there is a puncture, Tubeless tyres
- unlike tyres with inner tubes - go flat very slowly. This offers greater riding safety. A
tyre that goes flat very slowly can be repaired with an "Inflate and Repair" spray. Tyres
should be later fully repaired or replaced at an Authorised Service Centre.
56
